Custom Horse Trailers in Calgary

At Light Speed Trailers, we work with Platinum Manufacturing to help you create your dream custom horse trailer in Calgary. Offering more than 40 standard base options, they can build a trailer customized to your specifications. With more than 500 options to choose from, we will change the height, width and length from any of our standard models. Contact us today for more information.

Bumper Pull Slant Load Standard Models

•

  XB7112D

  • 2 Horse Platinum Series
  • 7x11x7 tall
•

  XB7153D

  • 3 Horse Platinum Series
  • 7x15x7 tall
•

  XB7184D

  • 4 Horse Platinum Series
  • 7x18x7 tall

Standard Features:

• Custom graphics package
• Wedge nose
• Permanent slant bulkhead wall
• Permanent offset rear storage wall (rear tack)
• Double rear doors with windows and butterfly latch
• Dressing room door at front with window and camper latch with deadbolt
• Walk through door at first stall with window and butterfly latch*
• Drop down feed doors with windows at head of each stall
• All doors are insulated and double walled
• Bus windows at hip of each stall
• Side walls in horse compartment are double walled and insulated
• All walls in horse compartment are rubber lined
• Dividers with stainless steel slam latches
• Feed bags (one per horse)
• 2-way roof vents (one per horse)
• Inside ties (two per horse)
• Outside ties (two per horse)
• Saddle racks (one per horse)
• Tack accessories
• Ten bridle hooks
• Two brush trays
• One blanket bar
• Padded butt bar and padded breast bar at first horse
• Padding in horse compartment on bulkhead wall, rear tack wall and each side of dividers
• Carpet all tack accessories (excluding bridle hooks)
• Carpet on floor of dressing room area
• Floor mats covering entire horse compartment including rear tack
• Teardrop fenders
• Full-width rubber dock bumper
• Five interior lights
• Fully enclosed tail lights
• DOT approved running lights and DOT approved reflective tape

* Walkthrough door not available on 2 Horse and no padded breast bar at first horse

Towing

• 2 5/16'' bulldog coupler (12,500# rating)
• Safety chains with safety hook latches
• Breakaway kit
• 7-way flat prong Plug and cable
• A-frame jack with removable caster

Wheels and Tires

• Four stainless steel simulators
• Spare tire carrier

2 Horse

• Five 15x6 steel wheels
• Five 225/75R15 6-ply radial tires
• 102'' Wide rubber torsion
• 3500# 5 or 6-bolt electric brakes

3 Horse

• Four stainless steel simulators
• Spare tire carrier
• 102'' Wide rubber torsion
• 5200# 8-bolt electric brakes

4 Horse

• Four stainless steel simulators
• Spare tire carrier
• 102'' Wide rubber torsion
• 7000# 8-bolt electric brakes

Bumper Pull Slant Load Warmblood Models

•

  XB7132D

  • 2 Horse 10' Long
  • 7x13x7.6" tall
•

  XB7163D

  • 3 Horse
  • 7x16x7.6" tall

Bumper Pull Straight Load Standard Models

Trailer dimensions for "smooth skin" models are the same as standard models.

•

  XB6102S

  • 2 Horse 10' Long
  • 6x10x7 tall
•

  XB6142S

  • Horse 14' Long
  • 6x14x7 tall
• SB6102S

  • 2 Horse 10' Long Smooth Skin
  • 6x10x7 tall
• SB6142S

  • 2 Horse 14' Long Smooth Skin
  • 6x14x7 tall

Standard Features:

• Custom Graphics Package
• Wedge nose (14' long)
• Straight nose (10' long)
• Permanent straight bulkhead wall*
• Double rear doors with windows and butterfly latch
• Dressing room door at front with window and camper latch with deadbolt*
• Swing out feed doors with window (one each side)
• Escape doors (one each side)
• Feed manager at head of each horse with 2 saddle compartment doors
• 2-way roof vents (one per horse)
• Removable divider with withers shield and permanent head shield
• All walls in horse compartment are rubber lined
• Side walls in horse compartment are double walled and insulated
• Bus windows with bars in horse compartment (one each side)
• All doors are insulated and lined on inside of trailer
• Inside ties (two per horse)
• Outside ties (two per horse)
• Saddle racks (one per horse)
• Padded butt bar and padded breast bar in each stall
• Padding in horse compartment on stall walls, manger wall and each side of divider
• Carpet on floor of dressing room area*
• Floor mats covering entire horse compartment including saddle compartment
• Teardrop fenders
• Full-width rubber dock bumper
• Five interior lights
• Fully enclosed tail lights
• DOT approved running lights
• * Not available on 10' long model

Tack Accessories

• Ten bridle hooks
• Two brush trays
• One blanket bar

Towing

• 2 5/16'' Bulldog Coupler (12,500# rating)
• Safety chains with safety hook latches
• 7-way flat prong plug and cable
• A-frame jack with removable caster
• Breakaway kit

Wheels and Tires

• Five 15x6 steel wheels
• Five 225/75R15 6-ply radial tires
• Four stainless steel simulators
• Spare tire carrier

Axles

• 96'' Wide rubber torsion
• 3500# 5-bolt electric brakes

Bumper Pull Straight Load Thoroughbred Models

Trailer dimensions for "smooth skin" models are the same as standard models.

•

  XB6112S

  • 2 Horse
  • 6x11x7 tall
• SB6112S

  • 2 Horse Smooth Skin
  • 6x11x7 tall

Wedge Nose

• Full-width rear ramp with dutch doors above with windows
• Walk thru doors with window, camper latch and butterfly latch (one each side)
• All doors are insulated and lined on inside of trailer
• Bus windows w/ bars in horse compartment (one each side)
• Side walls in horse compartment are double walled and insulated
• All walls in horse compartment are rubber lined
• Removable divider with withers shield and swinging head shield pinned to removable post

Front of trailer

• Feed bags (one per horse)
• 2-way roof vents (one per horse)
• Inside ties (two per horse)
• Outside ties (two per horse)
• Padding in horse compartment, on stall side walls and each side of divider
• Padded butt bar and breast bar in each stall
• Floor mats covering entire horse compartment
• Taper inner wheel wells up and teardrop fenders
• Rubber dock bumpers
• Three interior lights
• Two pairs of fully enclosed LED tail lights
• DOT approved LED running lights

Towing

• 2 5/16'' Bulldog Coupler (12,500# rating)
• Safety chains with safety hook latches
• 7-way flat prong plug and cable
• A-frame jack with removable caster
• Breakaway kit

Wheels and Tires

• Five 15x6 steel wheels
• Five 225/75R15 6-ply radial tires
• Four stainless steel simulators
• Spare tire carrier

Axles

• 96'' Wide rubber torsion
• 3500# 5-bolt electric brakes

Bumper Pull Straight Load Warmblood Models

•

  XB7162S

  • 2 Horse
  • 7x16x7'6 tall
•

  SB7162S

  • 2 Horse Smooth Skin
  • 7x16x7'6"

Wedge Nose

• Permanent straight bulkhead wall
• Full-width rear ramp with dutch doors above with windows
• Dressing room door at front with window and camper latch with deadbolt
• Walk thru doors with window, camper latch and butterfly latch (one each side)
• All doors are insulated and lined on inside of trailer
• Bus windows w/ bars in horse compartment (one each side)
• Side walls in horse compartment are double walled and insulated
• All walls in horse compartment are rubber lined
• Tack accessories: ten bridle hooks
• Padding in horse compartment, on stall side walls and each side of divider
• Removable divider with withers shield and swinging head shield pinned to removable post at
• Padded butt bar and breast bar in each stall
• Carpet on floor of dressing room area
• Floor mats covering entire horse compartment
• Taper inner wheel wells up and teardrop fenders
• Rubber dock bumpers
• Four interior lights
• Two pairs of fully enclosed LED tail lights
• DOT approved LED running lights

Front of trailer

• Feed bags (one per horse)
• 2-way roof vents (one per horse)
• Inside ties (two per horse)
• Outside ties (two per horse)

Towing

• 2 5/16'' Bulldog Coupler (12,500# rating)
• Safety chains with safety hook latches
• 7-way flat prong plug and cable
• A-frame jack with removable caster
• Breakaway kit

Wheels and Tires

• Five 15x6 steel wheels
• Five 225/75R15 6-ply radial tires
• Four stainless steel simulators
• Spare tire carrier

Axles

• 102'' Wide rubber torsion
• 5200# 6-bolt electric brakes

Gooseneck Steel Frame Horse Trailer

Constructed on a steel frame, this gooseneck horse trailer is built to last yet have a reduced total trailer weight due to the aluminum skin. Contact Light Speed Trailers for further details about the available features and options.

•

  Legacy

  • 6' 8" wide
  • 7' tall (inside height)
  • 40" wide stalls throughout horse compartment
  • Steel frame aluminum skin
  • Full rear door with cam latch
  • Sealed tack room
  • Carpeted tack floor
  • 9236" aluminum tack door with deadbolt
  • Interior tack room light with hot lead
  • Bridle hooks
  • Blanket bars
  • Swing out saddle rack
  • Adjustable slam latch stall divider
  • 8" air gap on head side and tail side
  • Aerodynamic nose
  • Interior tie rings (one per horse)
  • Exterior tie rings (one per horse)
  • 5" channel framed wrap around tongue
  • Tubular steel uprights and roof bows on 16" centres
  • 3" x 2" angle cross members
  • 4 wheel electric brakes
  • Caulked exterior and interior seams
  • (2) 3,500lb spring axles on 2 horse bumper pull
  • (2) 6,000lb spring axles on 3 horse bumper pull
  • (2) 7,000lb spring axles on 4 horse bumper pull
  • (2) 6,000lb spring axles on 2 horse gooseneck
  • (2) 7,000lb spring axles on 3 and 4 horse gooseneck
  • Breakaway kit
  • Spare tire carrier
  • LED marker and tail lights
  • 2- Part epoxy primer (self-etching)
  • Acrylic enamel paint with urethane hardener
  • 5 Year structural warranty
